CNC Nesting Machine SCNZ-LHD-610-9KW
Machine Overview
The SCNZ-LHD-610-9KW CNC Nesting Machine is a fully automated panel-processing solution designed for high-volume furniture and cabinet manufacturing. Combining CNC nesting, automatic loading and unloading, integrated labeling, and horizontal drilling capabilities, this machine streamlines production workflows while improving efficiency, accuracy, and material utilization.
With a large working area, automatic tool changing system, and advanced drilling capabilities, it is ideal for manufacturers seeking faster production cycles and reduced manual handling.
Key Features
Fully Automated Workflow – Automatic loading, unloading, and labeling help reduce manual labor and increase production efficiency.
Powerful 9 kW HQD Spindle – Provides reliable cutting, routing, grooving, and profiling performance for a wide range of panel materials.
Large Processing Area – 1830 × 3050 mm working area accommodates oversized panels and high-volume production requirements.
Integrated Horizontal Drilling – Enables precise drilling operations without requiring additional equipment.
12-Position Automatic Tool Changer – Linear tool magazine allows fast tool changes, minimizing downtime during complex jobs.
High-Speed Movement – Travel speeds up to 75 m/min on X and Y axes support faster production cycles.
Precision Positioning – ±0.02 mm positioning accuracy ensures consistent machining quality and repeatability.
Vacuum Worktable – Securely holds panels during machining for improved accuracy and operational safety.
Taiwan HIWIN Guide Rails – Delivers smooth movement, durability, and long-term reliability.
Integrated Labeling System – Label printer positioned beside the spindle enables efficient component identification and tracking.
User-Friendly Operation – Weihong control system allows easy programming and operation, including direct drawing on the machine interface.
Heavy-Duty Industrial Design – Built for continuous production environments and demanding manufacturing applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model No. | SCNZ-LHD-610-9KW |
| Machine Type | CNC Nesting Machine with Auto Loading, Unloading, Auto Labeling & Horizontal Drilling |
| Working Area | 1830 × 3050 mm |
| Spindle | 9 kW HQD |
| Control System | Weihong Control System |
| Servo Motor | 1.5 kW Servo Motor |
| Guide Rails | Y25, X25, Z20 mm – Taiwan HIWIN |
| Rack Type | M=1.5 |
| Running Speed (X/Y) | 75 m/min |
| Running Speed (Z) | 15 m/min |
| Table Design | Vacuum Table |
| Tool Magazine | 12 Tools, Linear Type |
| Pressing Rollers | 2 Rollers |
| Computer Function | Direct Drawing and Programming on Device |
| Positioning Accuracy | ±0.02 mm |
| Vacuum Pump | 7.5 kW Air-Cooled (China) |
| Working Voltage | 415V / 50Hz / 3 Phase |
| Drilling Head | 9V2H |
| Labeling Printer | Installed Beside the Spindle |
| Loading & Unloading Table | Included |
| Selling Price | ₹26,27,520 |
| Discount Available | 15% |
Applications
Industries
Modular Furniture Manufacturing
Kitchen Cabinet Production
Wardrobe Manufacturing
Office Furniture Manufacturing
Interior Fit-Out and Joinery Workshops
Wood Panel Processing Industries
Customized Furniture Production Facilities
Processes
CNC Nesting
Panel Cutting and Optimization
Horizontal and Vertical Drilling
Grooving and Slotting
Routing and Profiling
Engraving and Carving
Component Labeling and Tracking
Automated Material Handling
Common Use Cases
Modular Kitchen Components
Wardrobes and Closets
Office Furniture Panels
Cabinet Doors and Shelves
Interior Decorative Panels
MDF, Plywood, HDF, and Particle Board Processing
Ready-to-Assemble Furniture Components
High-Volume Furniture Manufacturing
