CNC Six Side Drilling - SD-612A
SOLWOOD CNC Six Side Drilling Machine
Model No. : SD-612A
The SOLWOOD CD-612 CNC Six Side Drilling Machine is an advanced intelligent drilling and milling solution designed for high-speed modular furniture and panel processing industries. Equipped with a powerful SYNTEC control system, this machine delivers exceptional drilling accuracy, smooth automation, and reliable performance for modern furniture manufacturing applications.
Designed for six-side drilling, grooving, and milling in a single cycle, the CD-612 improves productivity, reduces manual handling, and ensures precise machining quality. The machine is ideal for processing MDF, particle board, plywood, laminated boards, and engineered wood panels used in modular kitchens, wardrobes, office furniture, and customized furniture production.
Key Features
- Advanced SYNTEC control system for intelligent and user-friendly machine operation.
- Complete six-side drilling and milling solution with automatic processing capability.
- Dual high-speed spindle system ensures accurate grooving and milling performance.
- Heavy-duty vertical and horizontal drilling units for versatile machining operations.
- Intelligent CNC automation reduces production time and improves machining accuracy.
- Suitable for batch production and customized furniture manufacturing.
- Heavy-duty machine structure ensures stable operation and long service life.
- Compatible with modern furniture CAD/CAM software and automation systems.
SYNTEC Control System Advantages
The machine is equipped with a professional SYNTEC CNC control system, widely used in advanced woodworking CNC machinery for high-speed and high-precision operation. The system offers intelligent automation, smooth multi-axis control, easy program management, and excellent compatibility with furniture design software. It also supports CAD/CAM integration, fast data processing, and user-friendly machine operation for modern furniture production industries.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | CD-612 |
| Machine Type | CNC Six Side Drilling Machine |
| Control System | SYNTEC CNC Control System |
| Milling Processing Equipment | Available |
| Spindle Type | ER32 |
| Shank Diameter | 10 mm / 1/2 inch |
| Spindle Motor Power | 3.5 kW × 2 |
| Spindle Speed | 18,000 RPM |
| Drilling Group Motor Power | 2.2 kW × 2 |
| Vertical Drilling Unit | 12 Upper + 9 Bottom |
| Horizontal Drilling Unit | 2+2 in X Direction, 2+2 in Y Direction (8 Total) |
| Board Processing Thickness | 10 – 55 mm |
| Board Processing Width | 40 – 1220 mm |
| Board Processing Length | 140 – 3000 mm |
| Operating Voltage | 380V / 50Hz |
| Operating Pressure | 0.6 – 0.8 MPa |
| Total Installed Power | 22 kW |
Machine Dimensions Weight | 6445 × 2840 × 2220 mm 3000 Kgs. |
Advanced Machine Functions
Intelligent Six-Side Processing
The CD-612 performs drilling and milling operations on all six sides of the panel without manual repositioning, increasing efficiency and reducing processing errors.
High-Speed Dual Spindle Technology
Equipped with dual 3.5 kW spindles operating at 18,000 RPM, the machine delivers smooth cutting, grooving, and milling performance with superior finishing quality.
Powerful Drilling Configuration
The advanced vertical and horizontal drilling setup allows precise processing for complex furniture components and customized production requirements.
Smart Automation & Software Integration
The SYNTEC system supports CAD drawing import, intelligent machining programs, and seamless integration with furniture manufacturing software for faster production workflow.
Heavy-Duty Industrial Construction
The rigid machine body ensures stable machining performance during continuous industrial production and minimizes vibration during high-speed operations.
