Fiber Laser Cutting Machine - SLM-3015 - 3 KW
SOLWOOD - Model No. - SLM-3015 - 3000W Fiber Laser Cutting Machine
Precision • Power • Performance
SOLWOOD presents the SLM-3015 Fiber Laser Cutting Machine (3000W), engineered for high-speed and high-precision industrial metal cutting applications. Designed with a heavy-duty structure and advanced motion control system, this machine ensures superior cutting quality, production efficiency, and long-term reliability.
Machine Configuration
Model: SOLWOOD SLM-3015
Working Area: 3000 mm × 1500 mm (Full Sheet Capacity)
Laser Power: MAX 3000W Fiber Laser Source
Working Voltage: 380V / 50Hz / 60A
Total Power Consumption: ≤ 35KW
Cutting Capability
Suitable for processing:
Stainless Steel
Carbon Steel
Galvanized Steel
Silicon Steel
Titanium Alloy
Pickled Plate and other metal sheets
Delivers clean cutting edges, minimal burr formation, and excellent surface finish.
Motion and Accuracy Performance
Maximum Moving Speed: 70 m/min
Reposition Accuracy: ±0.02 mm
Positioning Accuracy: ±0.05 mm
The precision transmission system ensures consistent repeatability and high-quality output in complex and batch production.
Heavy-Duty Mechanical Structure
Industrial welded steel machine bed
Thermal aging treatment to prevent deformation
High rigidity frame for vibration-free operation
Steel serrated working table for stable sheet support
Modular knife bars for easy maintenance
Automatic lubrication system for extended component life
Built for continuous industrial operation.
Advanced Transmission System
X & Y Axis: Taiwan YYC Helical Rack and Pinion
Z Axis: TBI Ball Screw
Linear Guide: High-precision square linear guide rails
Reducer: Precision reducer for stable torque transmission
Ensures smooth movement, long service life, and stable cutting accuracy.
Servo and Drive System
Leadshine 1.5KW Servo Motor
400W Servo Motor with Brake
High torque output
Faster acceleration and deceleration
Stable and energy-efficient performance
CNC Control System – Empower XC3000S
Professional laser control system
Easy graphic and nesting design
User-friendly interface
Supports AutoCAD and CorelDraw
Flexible, stable, and simple operation
Laser Cutting Head – Empower BM110E
Auto height adjustment
High sensitivity response
Anti-collision protection design
Consistent and precise cutting performance
Cooling System
S&A Dual Temperature Dual Control Water Chiller
Intelligent temperature management
Ensures stable laser operation
Extends laser source lifespan
Supported File Formats
DXF / DWG / PLT / AI / CAD / DST / GPX / DXP
Compatible with industry-standard design software.
Electrical and Safety Components
Schneider Electric / Chint Electric components
Red dot pointer positioning system
CNC automatic adjusting system
Standard Accessories Included
Laser Protective Glasses (1060–1064nm) – 1 Pair
Protective Lenses – 3 Pieces
Nozzles – 3 Pieces
Tool Box – 1 Set
