SC-300 - 5-in-1 Woodworking Combination Machine

SOLWOOD - SC-300, 5-in-1 Woodworking Combination Machine | Planer, Thicknesser, Saw, Spindle Moulder & Mortiser
Machine Type
Universal Combination Woodworking Machine
⭐ Key Features
5-in-1 Multi-Function Machine – Planer, Thicknesser, Circular Saw, Spindle Moulder & Mortiser in one compact unit
400 mm Working Width – Ideal for furniture and solid wood processing
Heavy-Duty Cast Iron Construction – Ensures vibration-free and accurate performance
Multiple Spindle Speeds – Suitable for profiling, shaping and tenoning jobs
Space Saving Design – Perfect for professional workshops & small factories
🔧 Technical Specifications
Planer Unit
Max Planing Width: 300 mm
Table Length: 1500 mm
Cutter Block Speed: 5700 RPM
Spiral Cutterhead Knives: 3 Nos. (300 × 25 × 3 mm)
Max Cutting Depth: 4 mm
Thicknesser Unit
Max Thickness Capacity: 220 mm
Min Thickness: 4 mm
Feed Speed: 7 m/min
Max Cutting Depth: 4 mm

Circular Saw Unit
Saw Blade Diameter: 250 mm
Blade Bore: 30 mm
Blade Speed: 4500 RPM
Max Cutting Height @ 90°: 75–80 mm
Max Cutting Height @ 45°: 50 mm
Sliding Table Length: Approx. 1600 mm

Spindle Moulder / Shaper
Spindle Diameter: 30 mm (Optional 32 / 35 / 50 mm)
Spindle Speeds: 2000 / 3100 / 4400 / 7000 RPM
Spindle Stroke: 115 mm
Max Tool Diameter: 160 mm
Max Tenoning Depth: 55 mm

Mortiser Unit
Table Size: 250 × 500 mm
Chuck Capacity: Up to 16 mm
Longitudinal Stroke: 205 mm
⚡ Power & Build
Motor Power: Approx. 2.2 – 3.0 kW (per function)
Power Supply: 3-Phase Industrial AC
Body Construction: Cast Iron & Steel
📦 Dimensions & Weight
Net Weight: Approx. 550 – 560 kg
Design: Compact multi-function layout
🪵 Ideal For
Furniture manufacturers
Solid wood workshops
Doors, frames, panels & joinery work
Professional carpentry units
📌 Package Includes
SOLWOOD SC300 Combination Machine
Standard fences & guards
Sliding table
Tool kit & user manual
